StarTech.com HDMI Extender over CAT6/5e with 3 Port Video Switch 4k 30Hz/115ft, 4K HDMI Switch Box, Video over HDBaseT with Auto Switcher
Product Number: SYNX6536173
$463.58
Loading...
Loading...
Product Description
StarTech.com HDMI Extender over CAT6/5e with 3 Port Video Switch 4k 30Hz/115ft, 4K HDMI Switch Box, Video over HDBaseT with Auto Switcher
HDMI Over CAT6 Extender w/ 3 Port Switch; 4K 30Hz/115ft (35m); 1080p/230ft (70m) over CAT5e/6; Manual/Priority/Auto Switching; Multiple Control Methods; Power over Cable; HDBaseT; TAA Compliant; IR Remote (No Batteries incl.); Mounting Brackets Incl.
Description:
This HDMI over CAT6 extender with 3-port HDMI switch features HDBaseT and is TAA Compliant.
Astonishing 4K over CAT6
This HDMI Extender with a built-in Switch is capable of extending 7.1 audio and 4K at 30Hz video up to 115ft (35m), or 1080p up to 230ft (70m). The transmitter and receiver kit is connected using a single CAT5e/6 cable to avoid the hassle of running multiple cables.
Simplified Professional Installation
The HDMI Switch Box and Extender supports Power-over-Cable, meaning both the transmitter and receiver can be powered by the same single power source. Power-over-Cable is great for extending video to areas where power outlets may be limited, such as industrial sites. Use the metal housing, grounding bolts and included mounting brackets to create professional installation options, ideal for digital signage, boardrooms, and tradeshow applications.
Effortless Control with Automatic Switching
The 4K 30Hz HDMI extender box features several methods of input adjustment. Auto-detect switching selects newly connected devices, whereas priority selection allows you to choose the default active port. The IR Remote Control (batteries not included) and serial switching, using the included RJ-11 to DB9 adapter, offer additional input selection methods.
VS321HDBTK is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Enable presenters to connect a wide range of devices to one display
Great for remote entertainment displays in restaurants, bars, or hotels
Create brilliant digital signage displays in large commercial settings
Optimize the location of your demo stations at tradeshows and in auditoriums
More from the Manufacturer
Astonishing 4K over CAT6
This HDMI Extender with a built-in Switch is capable of extending 7.1 audio and 4K at 30Hz video up to 115ft (35m), or 1080p up to 230ft (70m). The transmitter and receiver kit is connected using a single CAT5e/6 cable to avoid the hassle of running multiple cables.
Simplified Professional Installation
The HDMI Switch Box and Extender supports Power-over-Cable, meaning both the transmitter and receiver can be powered by the same single power source. Power-over-Cable is great for extending video to areas where power outlets may be limited, such as industrial sites. Use the metal housing, grounding bolts and included mounting brackets to create professional installation options, ideal for digital signage, boardrooms, and tradeshow applications.
Effortless Control with Automatic Switching
The 4K 30Hz HDMI extender box features several methods of input adjustment. Auto-detect switching selects newly connected devices, whereas priority selection allows you to choose the default active port. The IR Remote Control (batteries not included) and serial switching, using the included RJ-11 to DB9 adapter, offer additional input selection methods.
VS321HDBTK is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Enable presenters to connect a wide range of devices to one display
Great for remote entertainment displays in restaurants, bars, or hotels
Create brilliant digital signage displays in large commercial settings
Optimize the location of your demo stations at tradeshows and in auditoriums
More from the Manufacturer
- HDMI EXTENDER WITH SWITCH: This 3 Port HDMI Switch Box extends 4K 30Hz resolutions up to 115ft (35m) or 1080p up to 230ft (70m) using CAT6/CAT5e cabling | Receiver Unit included | 4:4:4 Chroma Subsampling | 7.1ch Audio | HDCP 1.4 | HDBaseT | TAA Compliant
- HDBASET CERTIFIED: 4K HDMI Automatic Switch and Extender is tested and certified by the HDBaseT Alliance to help ensure quality and compatibility | Great for Digital Signage and AV installers/integrators for commercial and professional environments
- CONFIGURATION AND CONTROL: Manual, Priority or Auto-Detect Switching Options | Push Button, IR Remote Control (Batteries Not Included) and Serial Commands allow for a variety of control options | Manual or Auto EDID Copy
- SINGLE POWER ADAPTER FLEXIBILITY: The power adapter can be placed at either the remote or local side in areas where power outlets may be limited; Power is delivered to the HDMI Video Switcher transmitter and receiver kit over the Ethernet cable (PoC)
- EASY INSTALLATION: Durable metal housing with built-in grounding bolts and included optional mounting brackets make it ideal for many environments. The unit features DB9 RS232 ports for serial control, an RJ11 cable and an RJ11 to DB9 adapter is included
- Video Extender Receiver is all you need for dependable and productive audio/video transmission
- 4096 x 2160 maximum video resolution for a vivid, crystal clear display with added productivity
- HDMI in allows convenient transfer of content and data to video extender receiver to ensure maximum dependability
- HDMI out enables you to transfer data from your devices to video extender receiver with added efficiency
- Twisted pair media type is very easy to connect and can carry both analog and digital data at the same time for maximum connection efficiency
- 3 input devices supported for maximum productive usability
- 230 ft maximum operating distance to allow efficient coverage and maximum usability
- 4K graphics mode for stunning, lively video quality
- Type M power plug type for a secure, hassle-free operation
- Desktop form factor allows hassle-free and easy usage with increased efficiency
Product Specifications
-
Application/UsageDigital Signage System Display
-
Brand NameStarTech.com
-
Connectivity TechnologyWired
-
Country of OriginTaiwan
-
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE) Restriction of Hazardous Substances (RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
-
Environmentally FriendlyYes
-
Form FactorDesktop
-
Graphics Modes4K
-
HDMI InYes
-
HDMI OutYes
-
Limited Warranty2 Year
-
Manufacturer Part NumberVS321HDBTK
-
Maximum Operating Distance230 ft
-
Maximum Video Resolution4096 x 2160
-
Media Type SupportedTwisted Pair
-
Network (RJ-45)Yes
-
Number of HDMI Inputs3
-
Number of HDMI Outputs1
-
Number of Input Devices Supported3
-
Number of Network (RJ-45) Ports2
-
Package ContentsHDMI Extender HDMI Receiver Remote Control Universal Power Adapter (NA/JP, UK, EU, ANZ) RJ11 Cable RJ11 to RS232 Converter Set of Mounting Screws Quick-Start Guide Mounting Brackets Rubber Feet
-
Power Plug TypeType M
-
Product ColorBlack
-
Product NameHDMI Extender
-
Product TypeVideo Extender Receiver
-
Receiver Depth6.30"
-
Receiver Height1.30"
-
Receiver Weight (Approximate)1.30 lb
-
Receiver Width4.10"
-
Twisted Pair Cable StandardCategory 6
