Netgear AV Line M4250-10G2F-PoE+ 8x1G PoE+ 125W 2x1G and 2xSFP Managed Switch (GSM4212P)
Product Number: SYNX5968913
$640.68
Loading...
Loading...
Netgear AV Line M4250-10G2F-PoE+ 8x1G PoE+ 125W 2x1G and 2xSFP Managed Switch (GSM4212P)
10 Ports - Manageable - 3 Layer Supported - Modular - 2 SFP Slots - 17.32 W Power Consumption - 125 W PoE Budget - Optical Fiber, Twisted Pair - PoE Ports - 1U High - Rack-mountable - Lifetime Limited Warranty
Description:
Switching Engineered for AV over IP
The NETGEAR AV Line M4250 series was designed with input from AV Professionals. The result is a line of switches built from the ground up to support 1Gb audio and video over IP with customized hardware and software along with dedicated service and support.
NETGEAR M4250 series key features:
Ranges from 8 to 16 ports with a variety of PoE+ and Ultra90 PoE++ options for 15.4W, 30W, 60W, 75W and 90W AVoIP endpoints
Uplink options include 1G for audio installations or standalone video installations as well as 10G uplinks for larger scale video deployments
Also includes 12-port multi-gigabit Ethernet and 16-port 1G/10G fiber models for plug and play aggregation in a star topology
Designed for a clean integration with traditionalrack-mounted, AV equipment
The M4250 switches come with a sleek, black display panel with status in front and all cabling plus additional status in the back
Reversed mounting is possible when ports are desired on the front of the rack
A second pair of rackmount ears allows the switches to be mounted recessed by 2-inches to allow for the cabling
Software-controlled fan adjustments enable the fans to be turned off when ambient temperature and PoE loads are appropriate for a totally fanless operation
Threaded holes on the bottom (4xM5 for 50x100mm VESA) and in front (1xM10 for clamps) allow for universal mountingoptionsoutside the rack as well NETGEAR M4250 series AV software features:
Pre-configured for audio and video over IP out of the box, the M4250 switches enable encoders and decoders to be connected with zero configuration
When more configuration is required, an AV web-based GUI is available at the switch IP address:8080
This interface has been specially designed for AV installers with specific AV-related controls made more accessible and with port-based profiles
For audio, profiles for Dante, Q-SYS and AES67 are built-in, as well as an AVB profile (AVB license sold separately
For video, the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Kramer KDS, Aurora Multimedia, ZeeVee, Atlona, Dante and SDVoE
Other AV CODECs and manufactures are supported as well as audio/video/ control mixed profiles
To further simplify star deployments, NETGEAR IGMP Plus brings multicast automation between all M4250 switches, and with M4300/M4500
Simply connect the switches together and you are done! NETGEAR M4250 series other software features:
All M4250 switches share the same high-end NETGEAR Layer 2 / Layer 3 switching engine for a consistent experience
All switches in the M4250 series have another main, IT web-based GUI for midsize Enterprise campus networks, IoT and IPTV
Additional features include static, RIP and PIM-SM, DM and SSM multicast routing, DHCP Server and PTPv2 Transparent Clock (1-step E2E)
AVB is the only feature requiring a license, all other advanced features are available license-free
Advanced classifier-based, time-based hardware implementation for L2 (MAC), L3 (IP) and L4 (UDP/TCP transport ports)
Selectable Port-Channel / LAG (802.3ad - 802.1AX) L2/L3/L4 hashing for fault tolerance and load sharing with any type of Ethernet channeling
Voice VLAN with SIP, H323 and SCCP protocols detection and LLDP-MED IP phones automatic QoS and VLAN configuration
Efficient authentication tiering with successive DOT1X, MAB and Captive Portal methods for streamlined BYOD
The NETGEAR AV Line M4250 series was designed with input from AV Professionals. The result is a line of switches built from the ground up to support 1Gb audio and video over IP with customized hardware and software along with dedicated service and support.
NETGEAR M4250 series key features:
Ranges from 8 to 16 ports with a variety of PoE+ and Ultra90 PoE++ options for 15.4W, 30W, 60W, 75W and 90W AVoIP endpoints
Uplink options include 1G for audio installations or standalone video installations as well as 10G uplinks for larger scale video deployments
Also includes 12-port multi-gigabit Ethernet and 16-port 1G/10G fiber models for plug and play aggregation in a star topology
Designed for a clean integration with traditionalrack-mounted, AV equipment
The M4250 switches come with a sleek, black display panel with status in front and all cabling plus additional status in the back
Reversed mounting is possible when ports are desired on the front of the rack
A second pair of rackmount ears allows the switches to be mounted recessed by 2-inches to allow for the cabling
Software-controlled fan adjustments enable the fans to be turned off when ambient temperature and PoE loads are appropriate for a totally fanless operation
Threaded holes on the bottom (4xM5 for 50x100mm VESA) and in front (1xM10 for clamps) allow for universal mountingoptionsoutside the rack as well NETGEAR M4250 series AV software features:
Pre-configured for audio and video over IP out of the box, the M4250 switches enable encoders and decoders to be connected with zero configuration
When more configuration is required, an AV web-based GUI is available at the switch IP address:8080
This interface has been specially designed for AV installers with specific AV-related controls made more accessible and with port-based profiles
For audio, profiles for Dante, Q-SYS and AES67 are built-in, as well as an AVB profile (AVB license sold separately
For video, the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Kramer KDS, Aurora Multimedia, ZeeVee, Atlona, Dante and SDVoE
Other AV CODECs and manufactures are supported as well as audio/video/ control mixed profiles
To further simplify star deployments, NETGEAR IGMP Plus brings multicast automation between all M4250 switches, and with M4300/M4500
Simply connect the switches together and you are done! NETGEAR M4250 series other software features:
All M4250 switches share the same high-end NETGEAR Layer 2 / Layer 3 switching engine for a consistent experience
All switches in the M4250 series have another main, IT web-based GUI for midsize Enterprise campus networks, IoT and IPTV
Additional features include static, RIP and PIM-SM, DM and SSM multicast routing, DHCP Server and PTPv2 Transparent Clock (1-step E2E)
AVB is the only feature requiring a license, all other advanced features are available license-free
Advanced classifier-based, time-based hardware implementation for L2 (MAC), L3 (IP) and L4 (UDP/TCP transport ports)
Selectable Port-Channel / LAG (802.3ad - 802.1AX) L2/L3/L4 hashing for fault tolerance and load sharing with any type of Ethernet channeling
Voice VLAN with SIP, H323 and SCCP protocols detection and LLDP-MED IP phones automatic QoS and VLAN configuration
Efficient authentication tiering with successive DOT1X, MAB and Captive Portal methods for streamlined BYOD
- Effectively reduces downtime with improved network performance
- IEC 60320 C14 plug/connector type for maximum usability with added reliability
- Features 10 networking ports to easily establish a local network or expand your existing one
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Can work as layer 3 routing for scalable network design
- Rack mounting enables you to organize wires & secure cables for professional installation
- Managed switch provides a reliable foundation for your network
- Gigabit Ethernet port for ultra-fast network speeds
- Optical Fiber media support for a dependable and productive connectivity
-
Brand NameNetgear
-
Compatible Rack Unit1U
-
Country of OriginThailand
-
Depth7.9"
-
Energy Efficiency ComplianceEnergy-related Products Directive (ErP)
-
Environmental ComplianceRestriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
-
Environmentally FriendlyYes
-
Ethernet TechnologyGigabit Ethernet
-
Expansion Slot TypeSFP (mini-GBIC)
-
Form FactorRack-mountable
-
Height1.7"
-
Layer Supported3
-
Limited WarrantyLifetime
-
ManageableYes
-
Manufacturer Part NumberGSM4212P-100NAS
-
Media Type SupportedOptical Fiber Twisted Pair
-
ModularYes
-
Network Technology1000Base-T 1000Base-X
-
Number of SFP Slots2
-
Plug/Connector TypeIEC 60320 C14
-
PoE (RJ-45) PortYes
-
PoE Budget125 W
-
Power Consumption17.32 W
-
Power Plug TypeType C
-
Power SourcePower Supply
-
Product LineAV Line
-
Product ModelM4250-10G2F-PoE+
-
Product NameAV Line M4250-10G2F-PoE+ 8x1G PoE+ 125W 2x1G and 2xSFP Managed Switch (GSM4212P)
-
Product TypeEthernet Switch
-
Shared SFP SlotNo
-
Total Number of Network Ports10
-
Width17.3"
