Raritan Dominion KX III DKX3-UST KVM Switchbox

Product Number: SYNX4814548
$1,054.44
Loading...
Ships Free - This items ships free with your order
Delivered by Tue 12/3 Wed 12/4 - This is an estimated delivery timeline
Non Returnable - This is a non returnable item
Loading...

Product Description

Raritan Dominion KX III DKX3-UST KVM Switchbox
2 Computer(s) - 1920 x 1080 - 2 x Network (RJ-45) - 8 x USB - USB 2.0 - 1 x HDMI - Rack-mountable, Desktop - 1 x DisplayPort - 1U
Description:
HIGH PERFORMANCE IP KVM SWITCH ACCESS

The Dominion KX User Stations are standalone appliances for high performance IP access to servers connected to Dominion KX III and KX IV switches, accessed by DSAM, RDP, VNC, VMware virtual machines, web links and SSH connections, together with optional CommandCenter integration. The slim form factor allows them to sit on a desk, be mounted in a standard 19" rack, or VESA-mounted on the back of a monitor. Deploy using standard Cat5 cabling and Ethernet/IP technology.

Simultaneously access, view, and control multiple servers, spread across one, two, or three (KX IV User Station) monitors. Or use the new keyboard and mouse sharing feature to work across 4, 6, 9 or more monitors! Web-based remote control of User Stations connected to wall monitors in studios and control rooms.

There are two Dominion User Stations. The original Dominion KX III User Station is recommended for use with the KX III, one or two monitors and servers up to 1080p. The new, high performance Dominion KX IV User Station is recommended for use with the Dominion KX IV-101, higher video resolutions up to 4K, larger numbers of KVM sessions and up to 3 monitors.

The Dominion User Stations can replace outdated analog matrix switches, supplement inflexible broadcast systems or be deployed anywhere hassle-free IP access is needed. They are perfect for broadcast labs, studios, control rooms, offices, and data centers.

HIGH PERFORMANCE KX III AND KX IV USER APPLIANCES

Two Powerful Intel-based platforms
Stream multiple video sessions at 30 to 60 frames per second
Ultra-fast connections and sub-second switching
Supports VGA, DVI, HDMI, USB-C & DisplayPort video
Virtual media, USB audio, Smartcard Dual video/monitor support with two Dominion KX IV-101's
KX IV User Station supports: 4K video, 3 monitors and more KVM sessions PRODUCTIVE AND POWERFUL USER INTERFACE

Multiple simultaneous IP connections across one, two, or three monitors
Mouse sharing feature supports 4, 6, 9 or more monitors
Scan servers and optionally save screenshots
Favorites and hot-key switching
Productive window management
Save & restore window layouts, even across multiple User Stations
Chinese, German and Japanese language support FLEXIBLE IP SOLUTION - EASY TO DEPLOY
Flexible dual LAN or WAN access
Use corporate and/or separate LAN
Connects with Cat5 cabling
Access hundreds of servers and devices
PC/Laptop access also available
Desktop, rack & VESA mountable
Support for RDP, VNC, VMware virtual machines, web links, SSH and DSAM connections
CommandCenter for centralized login and access
  • Switch between sources by using this KVM Switchbox without degradation of performance and eliminate the manual work
  • 1920 x 1080 resolution for high-quality video delivery
  • USB port for easy connectivity
  • The rack-mountable form factor provides convenient installation

Product Specifications

  • Brand Name
    Raritan
  • Depth
    7.5"
  • DisplayPort
    Yes
  • Form Factor
    Desktop Rack-mountable
  • HDMI
    Yes
  • Height
    1.7"
  • Input Voltage Range
    100-240V AC
  • Manufacturer Part Number
    DKX3-UST
  • Maximum Video Resolution
    1920 x 1080
  • Network (RJ-45)
    Yes
  • Number of Computers Supported
    2
  • Number of DisplayPorts
    1
  • Number of HDMI Ports
    1
  • Number of Network (RJ-45) Ports
    2
  • Number of USB Ports
    8
  • Product Line
    Dominion
  • Product Model
    DKX3-UST
  • Product Name
    Dominion KX III DKX3-UST KVM Switchbox
  • Product Series
    KX III
  • Product Type
    KVM Switchbox
  • Rack Height
    1U
  • USB
    Yes
  • USB 2.0
    Yes
  • Width
    6.5"
