Tripp Lite by Eaton 4-Port DVI over Cat5/6 Splitter/Extender, Box-Style Transmitter for Video, DVI-D Single Link, 200 ft. (60 m), TAA
Product Number: SYNX2788229
$273.96
Loading...
Loading...
Product Description
Tripp Lite by Eaton 4-Port DVI over Cat5/6 Splitter/Extender, Box-Style Transmitter for Video, DVI-D Single Link, 200 ft. (60 m), TAA
1920x1080 at 60Hz
Description:
The B140-004 transmits a DVI-D Single-Link signal to four monitors up to 200 ft. away using a single Cat5e/6 patch cable. To achieve maximum distance and resolution, use 24AWG Solid Wire Cat5e/6 cable (Tripp Lite's N202-Series). An additional DVI port is provided for the connection of a local monitor. This local DVI port can also be used to daisychain up to 3 units together, allowing for the connection of up to 13 monitors (12 remote, 1 local). Mounting hardware is included that allows the unit to be rackmounted, wallmounted or pole mounted. In addition, up to three units can be mounted in 1U of rack space using a Tripp Lite B132-004-RB 19" rackmount bracket. The B140-002 is compatible with all operating systems, and is plug and play, with no software or drivers required.
Installation is simple. Connect the B140-004 transmitter to a DVI source using a Tripp Lite P561-Series DVI cable (not included). Connect a Tripp Lite B140-series receiver (not included) to each display using a Tripp Lite P561-Series DVI cable (not included). Finally, each remote receiver is connected to an RJ45 port on the B140-004 using a single Cat5e/6 cable.
For longer extension distances, use a B140-1A0 or B140-1A0-WP active receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 150 ft., or a 1024 x 768 @ 60Hz signal up to 200 ft..
For shorter extension distances, use a B140-1P0 or B140-1P0-WP passive receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 50 ft., or a 1024 x 768 @ 60Hz signal up to 100 ft..
Further expand the range and number of monitors by using a B140-110 repeater unit. Add up to four remote units (three repeaters and one active receiver) to each channel of the B140-004, for a total of 4 displays per channel. (An active receiver should be the last unit in a channel) A 1920 x 1080 @ 60Hz signal can be extended up to 125 ft. from each repeater to the next unit in the channel, or a 1024 x 768 @ 60Hz signal can be extended up to 175 ft..
More from the Manufacturer
Installation is simple. Connect the B140-004 transmitter to a DVI source using a Tripp Lite P561-Series DVI cable (not included). Connect a Tripp Lite B140-series receiver (not included) to each display using a Tripp Lite P561-Series DVI cable (not included). Finally, each remote receiver is connected to an RJ45 port on the B140-004 using a single Cat5e/6 cable.
For longer extension distances, use a B140-1A0 or B140-1A0-WP active receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 150 ft., or a 1024 x 768 @ 60Hz signal up to 200 ft..
For shorter extension distances, use a B140-1P0 or B140-1P0-WP passive receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 50 ft., or a 1024 x 768 @ 60Hz signal up to 100 ft..
Further expand the range and number of monitors by using a B140-110 repeater unit. Add up to four remote units (three repeaters and one active receiver) to each channel of the B140-004, for a total of 4 displays per channel. (An active receiver should be the last unit in a channel) A 1920 x 1080 @ 60Hz signal can be extended up to 125 ft. from each repeater to the next unit in the channel, or a 1024 x 768 @ 60Hz signal can be extended up to 175 ft..
More from the Manufacturer
- Supports DVI-D Single-Link video resolutions up to 1920 x 1080 @ 60Hz
- For longer distances - Use a B140-1A0 or B140-1A0-WP active receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 150 ft., or a 1024 x 768 @ 60Hz signal up to 200 ft.
- For shorter distances - Use a B140-1P0 or B140-1P0-WP-1 passive receiver unit to extend a 1920 x 1080 @ 60Hz signal up to 50 ft., or a 1024 x 768 @ 60Hz signal up to 100 ft.
- Use 24AWG, Solid Wire Cat5e/6 cable, such as Tripp Lite's N202-Series, to achieve maximum distance and resolution
- Can further expand the range and number of monitors by adding B140-110 repeaters
- Compatible with all operating systems
- Plug and play, no software or drivers required
- Video Extender Transmitter is all you need for dependable and productive audio/video transmission
- 1920 x 1080 maximum video resolution for stunning, lively result with optimal viewing usability
- DVI in for your convenience and optimal audio/video output with maximum usage feasibility
- The B140-004 video extender transmitter provides plenty of freedom with wired connectivity
- 1 input devices supported for maximum productive usability
- 5 output devices supported for maximum productive usability
- 200 ft maximum operating distance to allow efficient coverage and maximum usability
- Full HD graphics mode provides optimal video output with remarkable picture clarity
Product Specifications
-
Brand NameTripp Lite by Eaton
-
Connectivity TechnologyWired
-
Country of OriginTaiwan
-
DVI InYes
-
Environmentally FriendlyYes
-
Graphics ModesFull HD
-
Limited Warranty1 Year
-
Manufacturer Part NumberB140-004
-
Maximum Operating Distance200 ft
-
Maximum Video Resolution1920 x 1080
-
Media Type SupportedTwisted Pair
-
Network (RJ-45)Yes
-
Number of DVI Inputs2
-
Number of Input Devices Supported1
-
Number of Network (RJ-45) Ports4
-
Number of Output Devices Supported5
-
Package ContentsMounting Hardware B140-004 DVI Over Cat5 Extender/Splitter, 4-Port Local Transmitter Unit 1 ft. DVI Daisychain Cable External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A) Owner's Manual
-
Product ColorBlack
-
Product ModelB140-004
-
Product NameDVI over Cat5 Extender/Splitter, 4-Port Local Transmitter Unit
-
Product TypeVideo Extender Transmitter
-
Transmitter Depth4"
-
Transmitter Height1.13"
-
Transmitter Width5"
-
Twisted Pair Cable StandardCategory 6
