Eaton Tripp Lite Series 100G Multimode 50/125 OM4 Fiber Optic Cable (12F MTP/MPO-PC F/F), LSZH, Magenta, 2 m (6.6 ft.)
Product Number: SYNX6475784
$126.76$154.36
Loading...
Loading...
Product Description
Eaton Tripp Lite Series 100G Multimode 50/125 OM4 Fiber Optic Cable (12F MTP/MPO-PC F/F), LSZH, Magenta, 2 m (6.6 ft.)
6.56 ft Fiber Optic Network Cable for Network Device, Patch Panel, Switch - First End: 1 x MTP/MPO Network - Female - Second End: 1 x MTP/MPO Network - Female - 400 Gbit/s - LSZH, OFNR - 50/125 µm
Description:
40/100 GbE Cable Supports Higher Bandwidths Needed for High-Density Data Networking
As the amount of traffic in data networks grows, so does the need for devices and fiber cables to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. This multimode 50/125 OM4 cable is an ideal choice for 100G Ethernet applications up to 100 meters (328 feet) at 1300 nm. It is also backward compatible with 10 Gb and 25 Gb networks, so you can future-proof your current application for an eventual upgrade to 400 Gb.
Magenta Jacket Helps Avoid Misidentification That Can Cause Costly Downtime
The OM4-rated cable has a magenta jacket to identify it as multimode in a crowded patch panel or switch and prevent it from becoming accidentally disconnected. The round low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion, making it suitable for poorly ventilated areas. The connectors' slim boots allow easy one-handed installation and removal of the cable.
As the amount of traffic in data networks grows, so does the need for devices and fiber cables to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. This multimode 50/125 OM4 cable is an ideal choice for 100G Ethernet applications up to 100 meters (328 feet) at 1300 nm. It is also backward compatible with 10 Gb and 25 Gb networks, so you can future-proof your current application for an eventual upgrade to 400 Gb.
Magenta Jacket Helps Avoid Misidentification That Can Cause Costly Downtime
The OM4-rated cable has a magenta jacket to identify it as multimode in a crowded patch panel or switch and prevent it from becoming accidentally disconnected. The round low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion, making it suitable for poorly ventilated areas. The connectors' slim boots allow easy one-handed installation and removal of the cable.
- OM4-rated cable recommended for 100 Gb speeds up to 100 meters (@ 1300 nm)
- Backward compatible with 10/25/40 Gb networks to facilitate future-proofing
- Magenta LSZH jacket allows easy ID in a crowded switch or patch panel
- This product is covered by a Lifetime Limited Warranty
- This network cable provides splendid performance and clear connectivity
- Features fiber optic cable type to better accommodate your precise power supply requirements with maximum charging productivity
- Stranded feature for better reliability and ensure maximum productivity
- Network Device device supported according to your requirements with maximum productivity
Product Specifications
-
Boot TypeSlim
-
Brand NameTripp Lite by Eaton
-
Cable Length6.56 ft
-
Cable TypeFiber Optic
-
Connector ColorBlack Magenta
-
Connector Type on First EndMTP/MPO Network - Female
-
Connector Type on Second EndMTP/MPO Network - Female
-
Connector on First End Details1 x MTP/MPO Network - Female
-
Connector on Second End Details1 x MTP/MPO Network - Female
-
Country of OriginChina
-
Data Transfer Rate400 Gbit/s
-
Device SupportedNetwork Device Patch Panel Switch
-
Environmentally FriendlyYes
-
FeaturesBendable Polished Connector (PC) Push-Pull Tab Stranded
-
Fiber Optic Cable Core/Cladding Specification50/125 µm
-
Fiber Optic ModeMulti-mode
-
Jacket ColorMagenta
-
Jacket TypeLSZH OFNR
-
Limited WarrantyLifetime
-
Manufacturer Part NumberN845B02M12MG
-
Product ModelN845B-02M-12-MG
-
Product NameN845B-02M-12-MG Fiber Optic Network Cable
-
Product TypeNetwork Cable
