StarTech.com Industrial RS232 to RS422/485 Serial Port Converter with 15KV ESD Protection

Product Number: SYNX3670229
$100.88
Ships Free - This items ships free with your order
Delivered by Wed 12/4 Thu 12/5 - This is an estimated delivery timeline
Non Returnable - This is a non returnable item

Product Description

StarTech.com Industrial RS232 to RS422/485 Serial Port Converter with 15KV ESD Protection
Convert an RS232 data signal to either RS485 or RS422 with this wall-mountable, ESD-protected adapter - Industrial RS232 to RS422/485 Serial Port Converter w/ 15KV ESD Protection - RS232 to RS485 Serial Converter - RS232 RS422 Adapter - RS232/422/485
Description:
The IC232485S Industrial RS232 to RS-422/485 Serial Converter is a bi-directional adapter that lets you adapt an RS232 data signal to either RS485 (2 or 4-wire) or RS422 and vice-versa, with support for baud rates up to 921.6 Kbps.
Ideal for industrial environments, the serial port converter provides 15KV ESD protection on all signal pins to protect costly and often sensitive control equipment against electrical damage. The serial converter also features a sturdy wall-mountable metal housing with Power, Tx and Rx LED indicators for simple status monitoring.
The adapter supports auto baud rate detection as well as RS-422 and RS485 mode detection, with an integrated dip switch for manual mode selection if needed, and supports connection distances of up to 4000ft (1200m).
Backed by a 2-year StarTech.com warranty and free lifetime technical support.
More from the Manufacturer
  • RS232 to 2/4-wire RS485 or RS422 conversion
  • Supports RS422 and RS485 auto detect and manual switching
  • ±15KV ESD protection on all signal pins
  • Supports baud rates up to 921.6 Kbps
  • Wall-mountable
  • Supports a maximum connection distance of 4000ft (1200m)
Guides & Information
Related Articles
 Need more information? Ask a Question

Product Specifications

  • Brand Name
    StarTech.com
  • Certifications & Standards
    CE FCC
  • Country of Origin
    China
  • Depth
    4.6"
  • Environmentally Friendly
    Yes
  • Form Factor
    Wall Mountable
  • Height
    0.9"
  • ISM Band
    No
  • Input Voltage
    5 V DC
  • Limited Warranty
    2 Year
  • Manufacturer Part Number
    IC232485S
  • Network (RJ-11)
    No
  • Network (RJ-45)
    No
  • Number of Serial Ports
    2
  • Package Contents
    Industrial RS232 to RS422/485 Serial Port Converter with 15KV ESD Protection 1 x Universal Power Adapter (NA/EU/UK) 1 x Instruction Manual
  • Parallel Port
    No
  • Phone Line (RJ-11)
    No
  • PoE (RJ-45) Port
    No
  • Product Color
    Black
  • Product Name
    Industrial RS232 to RS422/485 Serial Port Converter with 15KV ESD Protection
  • Product Type
    Device Server
  • Serial Port
    Yes
  • UNII Band
    No
  • USB
    No
  • Width
    2.3"
  • Wireless LAN
    No
