StarTech.com 2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane - Storage bay adapter - black
Loading...
$58.44
Loading...
Loading...
Product Description
StarTech.com 2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane - Storage bay adapter - black
Easy, trayless removal and insertion of dual 2.5in SATA hard drives from single 3.5in bay - sata backplane - sata mobile rack - sata enclosure - 2.5inhot swap bay - SATA hot swap
Description:
This 3.5in SATA hard drive hot-swap bay allows you to install two 2.5in SATA hard drives (HDD) or solid state drives (SSD) in an available/unused 3.5in floppy drive bay.
Featuring a convenient "no mounting required /easy eject" feature (like a tape cartridge or floppy disk), the hard drive hot swap bay doesn't require that the drives be installed in a tray - making it the ideal solution for quick and easy drive removals and insertions as part of a system building process, or integration into rackmount systems or industrial environments.
To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with a compatible controller.
Also a perfect addition for operating system image deployment and any task that requires being able to quickly access large volumes of data on the fly, the hot swap bay provides everything you need to expedite important projects while maintaining a reliable storage solution.
With support for SATA HDD speeds up to 6.0 Gbps, this backplane is fully compatible with RAID installations to ensure maximum performance and versatility for enhanced storage applications.
More from the Manufacturer
Featuring a convenient "no mounting required /easy eject" feature (like a tape cartridge or floppy disk), the hard drive hot swap bay doesn't require that the drives be installed in a tray - making it the ideal solution for quick and easy drive removals and insertions as part of a system building process, or integration into rackmount systems or industrial environments.
To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with a compatible controller.
Also a perfect addition for operating system image deployment and any task that requires being able to quickly access large volumes of data on the fly, the hot swap bay provides everything you need to expedite important projects while maintaining a reliable storage solution.
With support for SATA HDD speeds up to 6.0 Gbps, this backplane is fully compatible with RAID installations to ensure maximum performance and versatility for enhanced storage applications.
More from the Manufacturer
- Holds up to two SATA drives in a single 3.5" bay
- Trayless design: drives are not mounted into separate trays/enclosures
- Includes a plastic protective film for the bottom side of hard drive
- Aluminum construction
- 50,000+ insertion rating
- Power/Activity LED for each drive
- Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
- Supports 2.5" form factor SATA hard drives (HDD) and solid state drives (SSD)
- Plug-and-Play and Hot-Swap compatible
Need more information?
Ask a Question
Product Specifications
-
Additional InformationAluminum construction and 50,000+ insertion rating ensures longevity from both the HDD/SSD and bay Backed by a StarTech.com 2-year warranty and free lifetime technical support Quickly and easily install or remove HDD/SSD without having to open the chassis with the innovative trayless design
-
Brand NameStarTech.com
-
Compatible Drive Bay Width3.5"
-
Controller TypeSerial ATA
-
Country of OriginTaiwan
-
Depth5.3"
-
Drive InterfaceSATA/600
-
Environmental CertificationRoHS
-
Environmental ComplianceRestriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
-
Environmentally FriendlyYes
-
Form FactorInternal
-
Height0.9"
-
Host InterfaceSerial ATA/600
-
Limited Warranty2 Year
-
Manufacturer Part NumberHSB220SAT25B
-
Number of 2.5" Bays2
-
Number of Hard Drives InstalledNo
-
Number of Hard Drives Supported2
-
Number of Solid State Drive InstalledNo
-
Number of Solid State Drive Supported2
-
Number of Total Expansion Bays2
-
Package Contents2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane 2 x Lp4 To SATA And LED Adapter Cable 1 x 15-Pin SATA Power And LED Y Cable 2 x 7-Pin SATA Data Cable 2 x Hard Drive Protector Film 1 x Screw Kit 1 x Instruction Manual
-
Product ColorBlack
-
Product MaterialAluminum
-
Product Name2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane
-
Product TypeDrive Enclosure
-
Width4"
-
Wireless LANNo
