StarTech.com PCI Express to 2 PCI & 2 PCIe Expansion Enclosure System - Full Length - Expansion Bay - External - 4 slot - PCI Express Single Lane - PCI Full Length
Product Number: SYNX2507657
$542.59
Loading...
Loading...
Product Description
StarTech.com PCI Express to 2 PCI & 2 PCIe Expansion Enclosure System - Full Length - Expansion Bay - External - 4 slot - PCI Express Single Lane - PCI Full Length
Add Two PCI & Two PCI Express Expansion Card Slots to a Desktop or Laptop Computer System - pci expansion chassis - external pci slot - pci express to pci expansion box
Description:
The PEX2PCIE4L PCI/PCI Express Expansion Chassis provides a quick and simple I/O expansion solution to almost any PCI Express (PCIe) enabled system. Adding PCI/PCIe cards to a server or workstation, or providing a platform to swap cards between a mobile and desktop setup is a cost-effective and time-saving solution for maximizing the I/O capabilities of your system.
The external expansion chassis adds two full-length (38cm) PCI slots (32-bit/33MHz), as well as two PCIe x1 (single-lane) slots to a host computer through a single PCI Express connection. Providing total bandwidth up to 250MBps from the PCIe x1 host controller card allows the computer to function as though the expansion chassis cards were connected directly to the motherboard.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
The external expansion chassis adds two full-length (38cm) PCI slots (32-bit/33MHz), as well as two PCIe x1 (single-lane) slots to a host computer through a single PCI Express connection. Providing total bandwidth up to 250MBps from the PCIe x1 host controller card allows the computer to function as though the expansion chassis cards were connected directly to the motherboard.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
- Expansion bay providing 2 PCI ports (32-bit/33 MHz), and 2 PCIe single-lane ports (250MBps)
- Self-powered PCI/PCIe expansion system with an on/off button
- Rugged steel construction satisfies demands of industrial and server environments
- Supports both 5V and 3.3V & 5V add-in PCI cards
- Complies with PCI 2.3 and PCIe 1.1 specifications
- Supports advance error reporting including ECRC support
- Support add-in cards with extended length (38cm)
Related Articles
Need more information?
Ask a Question
Product Specifications
-
Application/UsageLaptop
-
Brand NameStarTech.com
-
Country of OriginTaiwan
-
Environmental ComplianceRestriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE)
-
Environmentally FriendlyYes
-
Height5.6"
-
Length15"
-
Limited Warranty2 Year
-
Manufacturer Part NumberPEX2PCIE4L
-
Package Contents1 x PCI Expansion box 1 x PCI Express Card 1 x 3 ft. DVIxD Cable 1 x Low Profile Bracket 1 x Screw Kit 3 x Power Cord 1 x Power Adapter 1 x Software CD 1 x Instruction Manual
-
Product ColorBlack
-
Product MaterialSteel
-
Product NamePCI Express to 2 PCI & 2 PCIe Expansion Enclosure System - Full Length
-
Product TypeExpansion Chassis
-
Width5.4"
