MSI Z790-P WIFI Desktop Motherboard - Intel Z790 Chipset - Socket LGA-1700 - ATX
Product Number: ETLZ1075822249
$231.04
Loading...
Loading...
Product Description
MSI Z790-P WIFI Desktop Motherboard - Intel Z790 Chipset - Socket LGA-1700 - ATX
Core i5, Core i7, Core i9, Pentium Gold, Celeron, Core i3 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - UDIMM, DIMM - 4 x Memory Slots - 2.5Gigabit Ethernet - IEEE 802.11 a/b/g/n/ac/ax - HDMI - DisplayPort - 6 x SATA Interfaces
Description:
PRO Z790-P WIFI
PRO Z790-P WIFI is designed with tons of flexible tools and convenient Wi-Fi solution with DDR5 memory version.
BUSINESS ELEGANCE
The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
PRO Z790-P WIFI is designed with tons of flexible tools and convenient Wi-Fi solution with DDR5 memory version.
BUSINESS ELEGANCE
The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
- Lightning Gen 5: The latest PCIe 5.0 solution with up to 128GB/s bandwidth for maximum transfer speed.
- Latest DDR5 Memory: A huge step of DDR performance enhancement with the latest DDR5 memory and MSI Memory Boost technology.
- Wi-Fi 6E: The latest wireless solution supports 6GHz spectrum, MU-MIMO and BSS color technology, delivering speeds up to 2400Mbps.
- Lightning USB 20G: Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1.
- Extended Heatsink Design: MSI extended PWM heatsink and enhanced circuit design ensures even high-end processors to run in full speed.
- M.2 Shield FROZR: Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster.
- 2.5G Network Solution: Featuring premium 2.5G LAN to deliver better network experience.
- EZ Debug LED: Easiest way to troubleshoot.
- Frozr AI Cooling: Detect CPU & GPU temperatures and automatically adjust system fan duty to a proper value.
- Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
- Compatible Intel Core i7 processor provides lightning fast speed and peak performance, even for the toughest tasks and intensive games
- DDR5 SDRAM slot for convenient installation of memory
- RAID supported levels provide data reliability and fault tolerance
- IEEE 802.11 a/b/g/n/ac/ax wireless standard support lets you connect to the internet and have instant access to social media, music, movies, and online games
- HDMI interface connects the top of the line PCs, Blu-ray players, and cutting edge Gaming Controllers
- DisplayPort host interface allows audio and video signals to be shared in a single cable transmission to ensure maximum efficiency
- ATX form factor brings a significant number of PCI slots, expansion slots, and peripheral ports with an enhanced heat dissipation capability
- 4 USB 2.0 ports offer the impressive data transfer speed of up to 60 Mb/sec
Related Articles
Need more information?
Ask a Question
Product Specifications
-
2.5Gigabit EthernetYes
-
Audio Channels7.1
-
BluetoothYes
-
Brand NameMSI
-
Chipset ManufacturerIntel
-
Chipset ModelZ790
-
Controller TypeSerial ATA/600
-
Country of OriginChina
-
Depth9.6"
-
DisplayPortYes
-
Form FactorATX
-
HDMIYes
-
Limited Warranty3 Year
-
Manufacturer Part NumberPROZ790PWIFI
-
Maximum Memory Supported128 GB
-
Memory Form FactorDIMM UDIMM
-
Memory TechnologyDDR5 SDRAM
-
Number of Memory Slots4
-
Number of Network (RJ-45) Ports1
-
Number of Onboard USB 2.0 Ports4
-
Number of Onboard USB 3.2 Ports5
-
Number of PCI Express x1 Slots1
-
Number of PCI Express x16 Slots3
-
Number of SATA Interfaces6
-
Number of USB 2.0 Ports4
-
Number of USB 3.2 Gen 1 Ports2
-
Number of USB 3.2 Gen 2 Type-A Ports1
-
Number of USB 3.2 Ports1
-
Onboard VideoCPU Dependent Video
-
Package ContentsPRO Z790-P WIFI Desktop Motherboard European Union Regulatory Notice Quick Installation Guide Wi-Fi Antenna 2 x SATA Cables I/O Shiled 3 x M.2 Clips Driver DVD
-
Processor Generation Supported13th Gen
-
Processor SocketSocket LGA-1700
-
Processor SupportedCeleron Core i3 Core i5 Core i7 Core i9 Pentium Gold
-
Product ModelZ790-P WIFI
-
Product NamePRO Z790-P WIFI Desktop Motherboard
-
Product SeriesPRO
-
Product TypeDesktop Motherboard
-
RAID Levels0 1 10 5
-
RAID SupportedYes
-
Total Number of Expansion Slots4.0
-
Total Number of Onboard USB Ports9
-
Total Number of PCI Express Slots4
-
Total Number of USB Ports8
-
Total Processor Supported1
-
Width12"
-
Wireless LANYes
-
Wireless LAN StandardIEEE 802.11 a/b/g/n/ac/ax
