MSI MAG MAG X670E TOMAHAWK WIFI Gaming Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
Product Number: ETLZ1077025441
$296.36
Loading...
Loading...
MSI MAG MAG X670E TOMAHAWK WIFI Gaming Desktop Motherboard - AMD X670 Chipset - Socket AM5 - ATX
Ryzen 7 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - UDIMM, DIMM - 4 x Memory Slots - Gigabit Ethernet - 2.5Gigabit Ethernet - IEEE 802.11 a/b/g/n/ac/ax - HDMI - DisplayPort - 4 x SATA Interfaces
Description:
The MAG series fights alongside gamers in pursuit of honor.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability. Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation, ensuring even high- end processors to run in full speed. M.2 Shield Frozr
Keeps M.2 SSDs safe while preventing throttling, making them run faster. Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat. 7W/mK Thermal Pad & Additional
Choke Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performcance.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability. Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation, ensuring even high- end processors to run in full speed. M.2 Shield Frozr
Keeps M.2 SSDs safe while preventing throttling, making them run faster. Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat. 7W/mK Thermal Pad & Additional
Choke Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performcance.
- Supports AMD Ryzen 7000 Series Desktop Processors
- Supports DDR5 Memory, up to 6600+(OC) MHz
- Enhanced Power Design: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen5 M.2, USB 3.2 Gen 2x2
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
- AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
- High Quality PCB: 8-layer PCB made by 2oz thickened copper and server grade level material
- Ryzen 7 processors supported for enhanced, dependable system performance with maximum usability
- With DDR5 SDRAM get efficient data transfer rate and enhanced computer's performance
- Wireless support reduces the number of cables required to connect peripherals
- HDMI interface connects variety of HD devices including Gaming Controllers, Blu-ray players, laptops, PCs, digital cameras and many others for you to experience the ultimate HD display
- DisplayPort host interface lets you conveniently connect multiple monitors to increase productivity
- Retrieve a significant number of PCI slots, expansion slots, and peripheral ports that have an enhanced heat dissipation capability with the ATX gaming desktop motherboard
Related Articles
Need more information?
Ask a Question
-
2.5Gigabit EthernetYes
-
Audio Channels7.1
-
BluetoothYes
-
Bluetooth StandardBluetooth 5.3
-
Brand NameMSI
-
Chipset ManufacturerAMD
-
Chipset ModelX670
-
Controller TypeSerial ATA/600
-
Depth9.6"
-
DisplayPortYes
-
Form FactorATX
-
Gigabit EthernetYes
-
HDMIYes
-
HDMI Version2.1
-
Manufacturer Part NumberX670ETMAHAWIFI
-
Maximum Memory Supported128 GB
-
Memory Form FactorDIMM UDIMM
-
Memory TechnologyDDR5 SDRAM
-
Number of Memory Slots4
-
Number of Network (RJ-45) Ports1
-
Number of Onboard USB 2.0 Ports4
-
Number of Onboard USB 3.2 Ports6
-
Number of PCI Express x16 Slots3
-
Number of SATA Interfaces4
-
Number of USB 3.2 Gen 1 Type-A Ports4
-
Number of USB 3.2 Gen 2 Type-A Ports2
-
Number of USB 3.2 Gen 2 Type-C Ports1
-
Onboard VideoCPU Dependent Video
-
PCI Express StandardPCI Express 3.0 PCI Express 4.0 PCI Express 5.0
-
Package ContentsMAG X670E TOMAHAWK WIFI Gaming Desktop Motherboard Quick Installation Guide European Union Regulatory Notice 2 x Sata cables 3 x M.2 clip Cable Stickers Wi-fi Antenna M.2 Plate Screw
-
Processor SocketSocket AM5
-
Processor SupportedRyzen 7
-
Product LineMAG
-
Product ModelMAG X670E TOMAHAWK WIFI
-
Product NameMAG X670E TOMAHAWK WIFI Gaming Desktop Motherboard
-
Product TypeGaming Desktop Motherboard
-
RAID Levels0 1 10
-
RAID SupportedYes
-
S/PDIFYes
-
Total Number of Expansion Slots3.0
-
Total Number of Onboard USB Ports9
-
Total Number of PCI Express Slots3
-
Total Number of USB Ports8
-
Total Processor Supported1
-
Width12"
-
Wireless LANYes
-
Wireless LAN StandardIEEE 802.11 a/b/g/n/ac/ax
